Twin wire fence

Twin wire mesh panel and post system is made with "twin" horizontal wires to provide an exceptionally rigid fence.

Twin horizontal wires welded to 5mm verticals, often referred to as 656.? This system is also available in extra heavy duty 868 specification which has 8mm twin horizontal wires welded to 6mm verticals.

The Pro-twin system can be supplied in a range of heights including 1m, 2m and 2.4m and by combining panels a range of fence heights can be achieved up to at least 4m.

Posts are manufactured from different specifications of steel tube to suit the fence height.? Fixings to attach the panels to the posts are made from steel backed by anti-rattle rubber pads and fixed to the posts by stainless steel tamper-proof security bolts.

Panel Height x Width (mm)	Mesh size (mm)	Wire combination			Post Height (mm)
		Wire dia mm	Wire dia mm	Wire dia mm
630×2500	50×200	8×2+6	6×2+5	6×2+4	1100
830×2500	50×200	8×2+6	6×2+5	6×2+4	1300
1030×2500	50×200	8×2+6	6×2+5	6×2+4	1500
1230×2500	50×200	8×2+6	6×2+5	6×2+4	1700
1430×2500	50×200	8×2+6	6×2+5	6×2+4	1900
1630×2500	50×200	8×2+6	6×2+5	6×2+4	2100
1830×2500	50×200	8×2+6	6×2+5	6×2+4	2400
2030×2500	50×200	8×2+6	6×2+5	6×2+4	2600
2230×2500	50×200	8×2+6	6×2+5	6×2+4	2800
2430×2500	50×200	8×2+6	6×2+5	6×2+4	3000
