Steel Picket Fence

Metal Fence

Steel Picket Fence

Steel picket fence is also known as tubular fencing can be made from either steel, aluminum or wrought iron. Tubular steel offers a simple, affordable and stylish option for you.


Steel picket fence is also known as tubular fencing can be made from either steel, aluminum or wrought iron. Tubular steel offers a simple, affordable and stylish option for you. All tubular fencing can be custom designed to suit your requirements.

Panels
Fence panels are manufactured of the highest-strength steel pickets and rails, and are available in a wide range of sizes and styles.

Posts
Panels are attached with high-strength steel brackets to galvanized and powder-coated square tubular steel posts.

Gates
Choose from the widest available range of gate offerings, including opening configurations: Swing, Slide or Cantilever.

Coating
Hot dipped galvanized/painted/PVC coated

Colors
RAL standard colors are available.

Model Type TFL TFS TFH
Panel Height(mm) 1100-2200 1100-2200 1100-2200
Panel Width (mm) 2500-3000 2950-3200 2950-3200
Post Size (mm) 50 x 50 60 x 60 75 x 75
Vertical Picket Spacing (mm) 110 110 110
Horizontal Rail Size (mm) 32x32 40x40 45x45
Vertical Picket Size(mm) 16x16, 16x19 19x19, 16x19 25x25, 19x25
